TG63-150 Datasheet
Static
Static/Dynamic
Tests
CPTm
CPTu
-
-
-
Weight (gasoline version)
2205 pounds - (1000kg)
Weight (diesel version)
2315 pounds - (1050kg)
Tests
CPTm
CPTu
DPSH (standard)
DPH (optional)
DPM (optional)
Weight (gasoline version)
2425 pounds - (1100kg)
Weight (diesel version)
2535 pounds - (1150kg)
Stabilizers
Maximum thrust capacity
150 kN - 33721 pounds
Maximum extraction capacity
160 kN - 35969 pounds
Speed of the test
0.065 foot/s - 2 cm/s
Carriage
Hydrostatic operating tracks with planetary
reduction gear and negative brake
Speed 2 km/hour - 1,24 miles/hour
Max. forward slope 25%
Max. lateral slope 10%
Anchoring system
2, one for each side of the penetrometer
with gear motor
Torque: 160 kgm – 13887 inch-pound - 1570 Nm
Modular helical rod
3, with hydraulic action with articulated feet
Engine
Gasoline Engine (standard)
2 cylinders V 60°
23 Hp - 16.9kW
Air-cooling
Diesel Engine (optional)
2 in-line cylinders
15.8 Hp - 11.6kW
Liquid cooling
Certifications
Our Pagani Geotechnical equipment is CE certified and compliant​.
As shown by the certifications Pagani have attained, the specifications of the machines have undergone verifications and have been found to comply with CE and USA CFR (Title 29 §1910 Subpart O) directives in order to guarantee users safe, cutting-edge products.
